WesAudio Limited Edition Prometheus Eclipse 500 Series Analog Passive Dual-Channel Equalizer

Manufacturer’s Description

Introducing the all-new Eclipse edition of our flagship products, _PROMETHEUS & _HYPERION, marking a major milestone in our software redesign journey. We’ve partnered with SLINT and Spyrosoft Synergy to create a sleek and intuitive GUI that complements the advanced capabilities of our equalizers.

To celebrate this momentous occasion, we’re excited to announce the limited-edition Eclipse version of our equalizers. We’ve heard our customers asking this for years, and we are thrilled to offer a black faceplate option that perfectly complements the software redesign. These limited-edition units will be available at the same price as our regular units, and the major software update will work seamlessly with both white and black faceplates. Please note that this is a limited run, and we’ll only produce as many units as requested.

_PROMETHEUS is fully analog passive EQ with +24dBu of headroom. Featuring a pultec-style warm sound with a lot of innovative improvements, its modern approach to design allows instant recall of your classic vibe through a very flexible plugin. _PROMETHEUS as all ng500 products, integrates with your DAW environment via front panel USB socket or _TITAN chassis.

Features

• +24dBu of headroom
• Stereo / Dual mono / Mid/Side operation mode
• Passive equalizer (Pultec-style) design based on inductors
• Analog inductor
• Proprietary THD implementation
• Flexible DAW/Live plug-in control for instant recall
• 6 touch sensitive encoders allow to record automation
• True bypass
• In and OUT metering with clip detection
• A/B compare feature
• Low frequency boost/cut – 20, 30, 60, 100, 120, 250 Hz.
• High frequency boost – 2, 3, 4, 5, 8, 10, 12, 16 kHz.
• High frequency cut – 4, 8, 12, 20 KHZ.

Specifications

• Frequency response: 10Hz-150kHz (-2dB)
• THD+N < 0.01%: (1kHz,0dBu)
• Input impedance: 10kohm
• Output impedance: < 100ohm
• Max signal level: +24dBu
• Crosstalk: < -100dB
• THD (MID switch): 1%
• THD (HIGH switch): 2.5%
• Power consumption: 70mA per rail
• Dimensions: 76x133x158mm
• Box dimensions: 105x162x234mm
• Warranty: 2 years
